Also, one end of the cable has a longer "shaft" than the other end. Does it matter which end goes where?

Do you have a hand throttle or a foot throttle?

Post some pics of the cable, the throttle assembly and the parts you have for a mount at the carb.  With the pics we should be able to get you pointed in the right direction.

Two different people trying from two different computers, won't post, just goes back to "New topic" after couple minutes.

Resize....exactly, looked into that yesterday....no computer wiz here.

I think its 700kb, no?

Email me the pics, irrebel@cox.net, or use photobucket, which is what I'm gonna do with them anyway.

Ray

Rebel, I sent the pics last night...German, that pic is close, looking for what bracket you have and how it holds the cable,
Thanks.

MOR36174

http://rexmar.com/page107.html

TLM31799SS

http://rexmar.com/page109.html

242 107

http://rexmar.com/page198.html




best pic i have right now, plate gets sandwiched between carb and intake.  you'll need a new gasket for the carb to plate, but u can silicone between plate and intake.  clip goes onto plate, cable gets clipped in.  ball gets mounted to carb throttle, quick disconnect gets threaded onto cable, adjust accordingly.  secure with lock nut.    enjoy boating.

Sorry about that, completely missed the email somehow.




In this one, the bracket laying on the floor, yeah gets bolted to a cable plate that mounts under the carburetor. But it doesn't look like that engine ever had that set up. The brackets on your engine, above, look to me like a traditional throttle linkage/kickdown set up from a car or truck. The third link KA0tyk posted is what that other bracket bolts to, either above or below the plate depending on push or pull setup. The bracket on the cable there must be for on your throttle pedal.


Ray
