Ok maybe i counted wrong because searching for starters for 169 teeth flex plate is not working..i only see 168 tooth starters?

Sent from my PantechP9070 using SoCal Jet Boats mobile app

So it doesnt matter if the starter itself has 9 or 11 teeth then?

Sent from my PantechP9070 using SoCal Jet Boats mobile app

A freaken mess....i started the " starter sounds like it disengaging to early" thread got all kinds of great input tried a buch and still nothing..its almost to me like the starter does bolt up close enuf to flex plate.

Sent from my PantechP9070 using SoCal Jet Boats mobile app

I have the same starter. You running a flex plate or a flywheel?

I should probably go read the other thread...  It just got so wordy.... LMAO

Hahaha...umm im assuming fly wheel...i thought flex plate was just another name for it...how can i tell the diff?

Sent from my PantechP9070 using SoCal Jet Boats mobile app

Flexplate is a heavy sheet metal disc with holes on it that has the ring welded to it, (used on an automatic transmission). A flywheel is constructed of cast iron (used on a manual transmission), much heavier and has the ring shrunk to it. It sounds like you either have a bent (taco shaped) flexplate or a flywheel with the ring misplaced.

Has it always done this?

GT

In pieces wen i bought it

Sent from my PantechP9070 using SoCal Jet Boats mobile app

It sounds to me like the ring on the flywheel is too far rearward, on a top starter motor, the ring gear gets moved toward the rear of the flywheel.

The flywheel would need to be removed and the ring heated up and flipped around and reinstalled back on the flywheel toward the front edge.

You could test this theory by removing the bendix shims from the starter and see if it improves, but it will not fix it, it will only get better.


I would pull the motor loose and set it on blocks in the boat and remove the flywheel and check it out. You can leave the motor hooked to fuel and electrical so you can test it before getting everything back together..

Hope this helps you get closer...

U think i should just buy flex plate?

Sent from my PantechP9070 using SoCal Jet Boats mobile app

No... I don't.

GT

Sorry but wat are bendix shims? If its the shims between block and starter then i hav none.

Sent from my PantechP9070 using SoCal Jet Boats mobile app

If you look at the nose housing of the starter where the Bendix slides back and forth on the shaft, you will see a funny looking bushing at the end toward the very nose of the starter, there are typically a couple of shims on there to limit how far the Bendix moves toward the starter.

Do you have a way to get a picture of the bendix that has been trying to start the boat? It may show signs of how far it engages.

Gt

So at the tip there?

Sent from my PantechP9070 using SoCal Jet Boats mobile app

Ooooooh ok...so then back to changing out flex plate?

Sent from my PantechP9070 using SoCal Jet Boats mobile app

Dang ok well thank sir for your wealth of knowledge mucho appreciated.

Sent from my PantechP9070 using SoCal Jet Boats mobile app

I have the same starter. You running a flex plate or a flywheel?

I should probably go read the other thread...   It just got so wordy.... LMAO
GT jets are you using a shim on your starter?

Sent from my PantechP9070 using SoCal Jet Boats mobile app

The only time they need to be shimmed is when the re-manufacturing company refaces the drive assembly.

You should have .020" to .030" clearance between the gear faces with the Bendix engaged.

You can check this with a paper clip between the teeth with the gear engaged. The easiest way to engage the teeth is with the solenoid pulled from the starter and you can simply pull on the plunger moving the Bendix into the gear.

GT

A freaken mess....i started the " starter sounds like it disengaging to early" thread got all kinds of great input tried a buch and still nothing..its almost to me like the starter does bolt up close enuf to flex plate.

Sent from my PantechP9070 using SoCal Jet Boats mobile app

update OK so here are sum pics of whats going on now ....ready to put new flex plate on...any suggestions.. 👍👎
